#include <ConfigurationInfo.h>

Public Member Functions
	ReactionInfo (const string &reactionName, const vector< string > &particleList)

string	reactionName () const

const vector< string > &	particleList () const

const pair< string, vector< string > > &	data () const

const pair< string, vector< string > > &	bkgnd () const

const pair< string, vector< string > > &	genMC () const

const pair< string, vector< string > > &	accMC () const

string	normIntFile () const

bool	normIntFileInput () const

void	display (string fileName="", bool append=true)

void	clear ()

void	setParticleList (const vector< string > &particleList)

void	setData (const string &classname, const vector< string > &args)

void	setBkgnd (const string &classname, const vector< string > &args)

void	setGenMC (const string &classname, const vector< string > &args)

void	setAccMC (const string &classname, const vector< string > &args)

void	setNormIntFile (const string &normIntFile, bool input=false)

Detailed Description

The reaction info holds all information that is specific to a particular reaction or final state. It is typically characterized by a set of unique observable particles in the detector. In order to create a reaction it must be given a name that is unique in the fit and also a list of strings that identify the particles.

Definition at line 489 of file ConfigurationInfo.h.

Constructor & Destructor Documentation

◆ ReactionInfo()

ReactionInfo::ReactionInfo	(	const string &	reactionName,
		const vector< string > &	particleList
	)

inline

The constructor.

Parameters

[in]	reactionName	a unique name to identify this reaction
[in]	particleList	a list of particles that define the reaction

Definition at line 499 of file ConfigurationInfo.h.

Member Function Documentation

◆ accMC()

const pair< string, vector<string> >& ReactionInfo::accMC ( ) const

inline

Returns the name of a DataReader and a vector of arguments (e.g. file names) to that DataReader for ACCEPTED MC associated with this reaction.

See also: setAccMC

Definition at line 552 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ bkgnd()

const pair< string, vector<string> >& ReactionInfo::bkgnd ( ) const

inline

Returns the name of a DataReader and a vector of arguments (e.g. file names) to that DataReader for BACKGROUND associated with this reaction.

See also: setBkgnd

Definition at line 536 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ clear()

void ReactionInfo::clear ( )

Clears all internal data for this reaction

Definition at line 914 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ data()

const pair< string, vector<string> >& ReactionInfo::data ( ) const

inline

Returns the name of a DataReader and a vector of arguments (e.g. file names) to that DataReader for DATA associated with this reaction.

See also: setData

Definition at line 528 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ display()

void ReactionInfo::display	(	string	fileName = `""`,
		bool	append = `true`
	)

Displays information about this reaction to the screen or writes it to file if a file name is passed in.

Parameters

[in]	fileName	(optional) name of file to write reaction info to
[in]	append	(optional) if true (default) information will be appended to the file, if false is passed in the file will be overwritten

Definition at line 661 of file ConfigurationInfo.cc.

◆ genMC()

const pair< string, vector<string> >& ReactionInfo::genMC ( ) const

inline

Returns the name of a DataReader and a vector of arguments (e.g. file names) to that DataReader for GENERATED MC associated with this reaction.

See also: setGenMC

Definition at line 544 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ normIntFile()

string ReactionInfo::normIntFile ( ) const

inline

Returns the name of the file that the normalization integral cache is written out to.

See also: setNormIntFile

Definition at line 560 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ normIntFileInput()

bool ReactionInfo::normIntFileInput ( ) const

inline

Returns a boolean that indicates whether this normIntFile should be used as input (true) or not (false).

See also: setNormIntFile

Definition at line 568 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ particleList()

const vector<string>& ReactionInfo::particleList ( ) const

inline

This returns the list of particles that characterize the reaction.

See also: setParticleList

Definition at line 517 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ reactionName()

string ReactionInfo::reactionName ( ) const

inline

This returns the unique name of the reaction.

Definition at line 510 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ setAccMC()

void ReactionInfo::setAccMC	(	const string &	classname,
		const vector< string > &	args
	)

inline

Sets the name of a DataReader and a vector of arguments (e.g. file names) to that DataReader for ACCEPTED MC associated with this reaction.

Parameters

[in]	classname	the name of the DataReader that will read ACCEPTED MC
[in]	args	arguments to the DataReader

See also: accMC

Definition at line 645 of file ConfigurationInfo.h.

◆ setBkgnd()

void ReactionInfo::setBkgnd	(	const string &	classname,
		const vector< string > &	args
	)

inline

Sets the name of a DataReader and a vector of arguments (e.g. file names) to that DataReader for BACKGROUND associated with this reaction.

Parameters

[in]	classname	the name of the DataReader that will read DATA
[in]	args	arguments to the DataReader

See also: data

Definition at line 621 of file ConfigurationInfo.h.

◆ setData()

void ReactionInfo::setData	(	const string &	classname,
		const vector< string > &	args
	)

inline

Sets the name of a DataReader and a vector of arguments (e.g. file names) to that DataReader for DATA associated with this reaction.

Parameters

[in]	classname	the name of the DataReader that will read DATA
[in]	args	arguments to the DataReader

See also: data

Definition at line 609 of file ConfigurationInfo.h.

◆ setGenMC()

void ReactionInfo::setGenMC	(	const string &	classname,
		const vector< string > &	args
	)

inline

Sets the name of a DataReader and a vector of arguments (e.g. file names) to that DataReader for GENERATED MC associated with this reaction.

Parameters

[in]	classname	the name of the DataReader that will read GENERATED MC
[in]	args	arguments to the DataReader

See also: genMC

Definition at line 633 of file ConfigurationInfo.h.

◆ setNormIntFile()

void ReactionInfo::setNormIntFile	(	const string &	normIntFile,
		bool	input = `false`
	)

inline

Sets the name of the file to use as the normalization integral cache

Parameters

[in]	normIntFile	name of the normalization integral file
[in]	input	use this normIntFile as input

See also: normIntFile

Definition at line 656 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ setParticleList()

void ReactionInfo::setParticleList ( const vector< string > & particleList )

inline

Sets the vector of strings that provides the names of the final state particles.

Parameters

[in] particleList vector of strings of final state particles

See also: particleList

Definition at line 598 of file ConfigurationInfo.h.

Here is the caller graph for this function:

The documentation for this class was generated from the following files:
