ComplexParameter Class Reference

#include <ComplexParameter.h>

Inheritance diagram for ComplexParameter:

Collaboration diagram for ComplexParameter:

Public Member Functions
	ComplexParameter (const string &name, MinuitMinimizationManager &aManager, complex< double > initialValue=complex< double >(1, 0), bool purelyReal=false)
	~ComplexParameter ()
void	update (const MISubject *callingSubject)
void	setValue (complex< double > value)
void	fix ()
void	free ()
const string &	name () const
string	realName () const
string	imagName () const
bool	isPurelyReal () const
bool	isFixed () const
complex< double >	value () const
const complex< double > *	constValuePtr () const
complex< double > *	valuePtr ()
Public Member Functions inherited from MIObserver
	MIObserver ()
virtual	~MIObserver ()

Detailed Description

This class manages the conversion of complex parameters to real parameters that minuit minimizes.

If a valid MinuitMinimizationManager reference is passed in it it registers two parameters with MinuitParameterManager when created. It is an also MIObserver – on update calls it maintains a complex< double > that represents the value of the parameter.

It is also useful to be able to create ComplexParameter objects with no connection to MinuitMinimizationManager in MPI implementations of the fitter. These objects are valid, but are not registered to or updated by the minimization manager.

Definition at line 68 of file ComplexParameter.h.

Constructor & Destructor Documentation

ComplexParameter()

ComplexParameter::ComplexParameter	(	const string &	name,
		MinuitMinimizationManager &	aManager,
		complex< double >	initialValue = complex< double >( 1, 0 ),
		bool	purelyReal = false
	)

This constructs the ComplexParameter.

Parameters

[in]	name	the string giving the name of the parameter, real and imaginary parts of the parameter will be identified in MINUIT with this string plus "_re" or "_im" appened.
[in]	aManager	an instance of the MinuitMinimizationManager with which to create and register the parameters
[in]	initialValue	an optional initial value
[in]	purelyReal	an optional argument that when set true forces the imaginary part of the complex number to zero

Definition at line 46 of file ComplexParameter.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

~ComplexParameter()

ComplexParameter::~ComplexParameter

(

)

This is the ComplexParameter destructor.

Definition at line 78 of file ComplexParameter.cc.

Member Function Documentation

constValuePtr()

const complex< double >* ComplexParameter::constValuePtr ( ) const

inline

A function that returns a const pointer to the value of the parameter. This is useful, for example, when telling the AmplitudeManager to use an external parameter for a production amplitude.

See also

AmplitudeManager::setExternalProductionAmplitude

Definition at line 167 of file ComplexParameter.h.

Here is the caller graph for this function:

fix()

void ComplexParameter::fix

(

)

This fixes the parameter at its current value.

Definition at line 114 of file ComplexParameter.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

free()

void ComplexParameter::free

(

)

This allows the parameter to float.

Definition at line 121 of file ComplexParameter.cc.

Here is the call graph for this function:

imagName()

string ComplexParameter::imagName ( ) const

inline

A function that returns the name of the parameter representing the imaginary part of the complex number.

Definition at line 142 of file ComplexParameter.h.

isFixed()

bool ComplexParameter::isFixed

(

)

const

A function to see if the parameter is floating.

Definition at line 128 of file ComplexParameter.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

isPurelyReal()

bool ComplexParameter::isPurelyReal ( ) const

inline

A function that returns a boolean indicating whether the parameter is purely real or not.

Definition at line 148 of file ComplexParameter.h.

Here is the caller graph for this function:

name()

const string& ComplexParameter::name ( ) const

inline

A function that returns the name of the ComplexParameter

Definition at line 130 of file ComplexParameter.h.

realName()

string ComplexParameter::realName ( ) const

inline

A function that returns the name of the parameter representing the real part of the complex number.

Definition at line 136 of file ComplexParameter.h.

setValue()

void ComplexParameter::setValue

(

complex< double >

value

)

This sets the value of the parameter.

Parameters

[in]

value

the desired value of the complex parameter

Definition at line 103 of file ComplexParameter.cc.

Here is the call graph for this function:

update()

void ComplexParameter::update ( const MISubject *  callingSubject )

virtual

This is called by the MinuitInterface and triggers the updating of the values of the real and imaginary parts of the complex parameter.

Parameters

[in]

callingSubject

pointer to the MinuitParameter representing either the real or imaginary part of the value

Implements MIObserver.

Definition at line 90 of file ComplexParameter.cc.

Here is the call graph for this function:

value()

complex< double > ComplexParameter::value ( ) const

inline

A function that returns the current value of the complex parameter.

Definition at line 158 of file ComplexParameter.h.

Here is the caller graph for this function:

valuePtr()

complex< double >* ComplexParameter::valuePtr ( )

inline

A function that returns a pointer (not const) to the value of the parameter.

Definition at line 173 of file ComplexParameter.h.

---

The documentation for this class was generated from the following files:

• ComplexParameter.h
• ComplexParameter.cc
