#include <ConfigurationInfo.h>

Public Member Functions
	ConfigurationInfo (const string &fitName)

	~ConfigurationInfo ()

string	fitName () const

string	fitOutputFileName () const

vector< string >	userKeywords () const

vector< vector< string > >	userKeywordArguments (const string &userKeyword) const

vector< ReactionInfo * >	reactionList (const string &reactionName="") const

vector< CoherentSumInfo * >	coherentSumList (const string &reactionName="", const string &sumName="") const

vector< AmplitudeInfo * >	amplitudeList (const string &reactionName="", const string &sumName="", const string &ampName="") const

vector< ParameterInfo * >	parameterList (const string &reactionName="", const string &sumName="", const string &ampName="", const string &parName="") const

ReactionInfo *	reaction (const string &reactionName) const

CoherentSumInfo *	coherentSum (const string &reactionName, const string &sumName) const

AmplitudeInfo *	amplitude (const string &reactionName, const string &sumName, const string &ampName) const

ParameterInfo *	parameter (const string &parName) const

ReactionInfo *	createReaction (const string &reactionName, const vector< string > &particleList)

CoherentSumInfo *	createCoherentSum (const string &reactionName, const string &sumName)

AmplitudeInfo *	createAmplitude (const string &reactionName, const string &sumName, const string &ampName)

ParameterInfo *	createParameter (const string &parName, double value)

void	removeReaction (const string &reactionName="")

void	removeCoherentSum (const string &reactionName="", const string &sumName="")

void	removeAmplitude (const string &reactionName="", const string &sumName="", const string &ampName="")

void	removeParameter (const string &parName="")

void	setFitName (const string &fitName)

void	addUserKeyword (const string &uesrKeyword, const vector< string > &arguments)

void	removeUserKeyword (const string &userKeyword="")

void	display (string fileName="", bool append=false) const

void	display (string fileName="", bool append=false)

void	write (const string &fileName) const

ostream &	write (ostream &output) const

map< string, vector< string > >	constraintMap () const

Detailed Description

The ConfigurationInfo class holds four types of objects:

REACTIONS (ReactionInfo Class)
- Reactions are uniquely specified by a reaction name.
- ReactionInfo must contain a vector of particle names. (These are used by the Kinematics class, for example, to keep track of four-vectors.)
- It also holds instructions for how to read data and MC.
COHERENT SUMS (CoherentSumInfo Class)
- Coherent sums are uniquely specified by a reaction name and a sum name.
- Every coherent sum must be associated with an existing reaction.
AMPLITUDES (AmplitudeInfo Class)
- Amplitudes are uniquely specified by a reaction name, a sum name, and an amplitude name
- Every amplitude must be associated with an existing reaction and sum.
- Every amplitude is a product of factors (specified by addFactor).
- In every amplitude factor (vector<string>), the first element is the amplitude class name, the other elements are passed into the amplitude class as arguments.
PARAMETERS (ParameterInfo Class)
- Parameters are uniquely specified by the parameter name.
- Associate parameters with amplitudes using the AmplitudeInfo class (addParameter)
- These parameters are in addition to production amplitude parameters (which are implied for every amplitude)

Use the ConfigurationInfo class to create instances of the above objects with the createX methods.

Return lists of objects with the xList methods.

The purpose of the ConfigurationInfo class is to organize all information that is necessary to perform an amplitude analysis. It can be setup directly by the user from the provided member functions or, alternatively, created by some tool. Currently the most popular method for setting up the fit configuration is to utilize the provided ConfigFileParser to setup the ConfigurationInfo object from a user-supplied text file. ConfigurationInfo can then be used to configure the AmplitudeManager and the ParameterManager.

See also: reactionList; coherentSumList; amplitudeList; parameterList

Definition at line 111 of file ConfigurationInfo.h.

Constructor & Destructor Documentation

◆ ConfigurationInfo()

ConfigurationInfo::ConfigurationInfo ( const string & fitName )

inline

The constructor, which takes the name of the fit being done.

Definition at line 118 of file ConfigurationInfo.h.

◆ ~ConfigurationInfo()

ConfigurationInfo::~ConfigurationInfo ( )

Definition at line 48 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Member Function Documentation

◆ addUserKeyword()

void ConfigurationInfo::addUserKeyword	(	const string &	uesrKeyword,
		const vector< string > &	arguments
	)

Add a user-defined keyword and its arguments. A user-defined keyword can have multiple sets of arguments.

See also: userKeywords; userKeywordArguments; removeUserKeyword

Definition at line 208 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ amplitude()

AmplitudeInfo * ConfigurationInfo::amplitude	(	const string &	reactionName,
		const string &	sumName,
		const string &	ampName
	)		const

Similar to amplitudeList above but returns a pointer to a specific amplitude. Note that the pointer is not const. This routine can be used to modify a CoherentSumInfo object in the configuration.

Parameters

[in]	reactionName	the name of the reaction
[in]	sumName	the name of the sum
[in]	ampName	the name of the amplitude

See also: amplitudeList

Definition at line 179 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ amplitudeList()

vector< AmplitudeInfo * > ConfigurationInfo::amplitudeList	(	const string &	reactionName = `""`,
		const string &	sumName = `""`,
		const string &	ampName = `""`
	)		const

This returns a vector of all amplitudes. Optionally the user can restrict the list to those associated with a particular reaction, coherent sum, or having a particular name. Passing in an empty string to any argumentimplies the search will not filter on that argument.

Parameters

[in]	reactionName	(optional) the name of the reaction
[in]	sumName	(optional) the name of the sum
[in]	ampName	(optional) the name of the amplitude

See also: amplitude

Definition at line 105 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ coherentSum()

CoherentSumInfo * ConfigurationInfo::coherentSum	(	const string &	reactionName,
		const string &	sumName
	)		const

Similar to coherentSumList above but returns a pointer to a specific sum. Note that the pointer is not const. This routine can be used to modify a CoherentSumInfo object in the configuration.

Parameters

[in]	reactionName	the name of the reaction
[in]	sumName	the name of the sum

See also: coherentSumList

Definition at line 165 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ coherentSumList()

vector< CoherentSumInfo * > ConfigurationInfo::coherentSumList	(	const string &	reactionName = `""`,
		const string &	sumName = `""`
	)		const

This returns a vector of all coherent sums. Optionally the user can restrict the list to those registered to a particular reaction and with a specific name. Passing in an empty string to either argument implies the search will not filter on that argument.

Parameters

[in]	reactionName	(optional) the name of the reaction
[in]	sumName	(optional) the name of the coherent sum

See also: coherentSum

Definition at line 91 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ constraintMap()

map< string, vector< string > > ConfigurationInfo::constraintMap ( ) const

This produces a map where the keys are the names of the amplitudes and the values are vectors of the names of the amplitudes whose production parameters are constrained to be the same as the key amplitude's production parameter.

Definition at line 399 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ createAmplitude()

AmplitudeInfo * ConfigurationInfo::createAmplitude	(	const string &	reactionName,
		const string &	sumName,
		const string &	ampName
	)

A routine to create a new amplitude. This returns a pointer to the amplitude that has been created so it can be further modified. If the amplitude already exists, it will be overwritten with a new amplitude.

Parameters

[in]	reactionName	the name of the reaction for which to create the amplitude
[in]	sumName	the coherent sum that the amplitude should be added to
[in]	ampName	the name of amplitude to be created

See also: removeAmplitude

Definition at line 255 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ createCoherentSum()

CoherentSumInfo * ConfigurationInfo::createCoherentSum	(	const string &	reactionName,
		const string &	sumName
	)

A routine to create a new coherent sum. This returns a pointer to the coherent sum that has been created so it can be further modified. If the coherent sum already exists, it will be overwritten with a new coherent sum.

Parameters

[in]	reactionName	the name of the reaction for which to create the coherent sum
[in]	sumName	the name of the sum to create

See also: removeCoherentSum

Definition at line 233 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ createParameter()

ParameterInfo * ConfigurationInfo::createParameter	(	const string &	parName,
		double	value
	)

This creates a new parameter and returns a pointer to the ParameterInfo object for that parameter so it can be further modifed. If the parameter already exists, it will be overwritten with a new parameter.

Parameters

[in]	parameterName	the name of the parameter to create
[in]	value	the initial value of the parameter

See also: removeParameter

Definition at line 284 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ createReaction()

ReactionInfo * ConfigurationInfo::createReaction	(	const string &	reactionName,
		const vector< string > &	particleList
	)

A routine to create a new reaction. This returns a pointer to the reaction that has been created so it can be further modified. If the reaction already exists, it will be overwritten with a new reaction.

Parameters

[in]	reactionName	the name of the reaciton to be created
[in]	particleList	a vector of the strings that identify the particles in the reaction

See also: removeReaction

Definition at line 217 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ display() [1/2]

void ConfigurationInfo::display	(	string	fileName = `""`,
		bool	append = `false`
	)		const

This displays a nicely formatted description of the configuration to the screen (when no arguments are specified) or prints to a file named by the first argument. If the second argument is set to true the configuration info will be appeneded to the file.

Parameters

[in]	fileName	(optional) name of file to write info
[in]	append	(optional) set to true to append to the file, default is to overwrite the file

Definition at line 604 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ display() [2/2]

void ConfigurationInfo::display	(	string	fileName = `""`,
		bool	append = `false`
	)

Definition at line 618 of file ConfigurationInfo.cc.

Here is the call graph for this function:

◆ fitName()

string ConfigurationInfo::fitName ( ) const

inline

A function to retreive the fit name.

Definition at line 124 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ fitOutputFileName()

string ConfigurationInfo::fitOutputFileName ( ) const

inline

Name of the fit results file.

Definition at line 130 of file ConfigurationInfo.h.

Here is the caller graph for this function:

◆ parameter()

ParameterInfo * ConfigurationInfo::parameter ( const string & parName ) const

Similar to parameterList above but returns a pointer to a specific parameter. Note that the pointer is not const. This routine can be used to modify a ParameterInfo object in the configuration.

Parameters

[in] parName the name of the parameter

See also: parameterList

Definition at line 195 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ parameterList()

vector< ParameterInfo * > ConfigurationInfo::parameterList	(	const string &	reactionName = `""`,
		const string &	sumName = `""`,
		const string &	ampName = `""`,
		const string &	parName = `""`
	)		const

This returns a vector of all parameters. The user can optionally restrict the list to those associated with a particular reaction, coherent sum, amplitude, or having a particular name. Passing in an empty string to any argumentimplies the search will not filter on that argument.

Parameters

[in]	reactionName	(optional) the name of the reaction
[in]	sumName	(optional) the name of the sum
[in]	ampName	(optional) the name of the amplitude
[in]	parName	(optional) the name of the parameter

See also: parameter

Definition at line 120 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ reaction()

ReactionInfo * ConfigurationInfo::reaction ( const string & reactionName ) const

Similar to reactionList above but returns a pointer to a specific reaction. Note that the pointer is not const. This routine can be used to modify a ReactionInfo object in the configuration.

Parameters

[in] reactionName the name of the reaction

See also: reactionList

Definition at line 153 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ reactionList()

vector< ReactionInfo * > ConfigurationInfo::reactionList ( const string & reactionName = "" ) const

This returns a vector of all registered reactions (ReactionInfo) objects when called without an argument. With an argument it returns a vector containg just those reactions that match the reaction name. Note that the list does not contain const pointers so the reactions themselves may be modified.

Parameters

[in] reactionName (optional) the name of the reaction

See also: reaction

Definition at line 77 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ removeAmplitude()

void ConfigurationInfo::removeAmplitude	(	const string &	reactionName = `""`,
		const string &	sumName = `""`,
		const string &	ampName = `""`
	)

This removes an amplitude or amplitudes that are matched to the arguments. Passing in a null string to a particular argument will match all instances of that argument (like a wildcard). The null string is the default argument for all parameters.

Parameters

[in]	reactionName	the name of the reaciton
[in]	sumName	the name of the sum
[in]	ampName	the name of the amplitude

See also: createAmplitude

Definition at line 345 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ removeCoherentSum()

void ConfigurationInfo::removeCoherentSum	(	const string &	reactionName = `""`,
		const string &	sumName = `""`
	)

This removes a coherent sum or sums that are matched to the arguments. Passing in a null string to a particular argument will match all instances of that argument (like a wildcard). The null string is the default argument for all parameters.

Parameters

[in]	reactionName	the name of the reaciton
[in]	sumName	the name of the sum

See also: createCoherentSum

Definition at line 326 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ removeParameter()

void ConfigurationInfo::removeParameter ( const string & parName = "" )

This removes an a parameter or parameters matched to the arguments. Passing in a null string to a particular argument will match all instances of that argument (like a wildcard). The null string is the default argument for all parameters

Parameters

[in] parName the name of the parameter

See also: createParameter

Definition at line 371 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ removeReaction()

void ConfigurationInfo::removeReaction ( const string & reactionName = "" )

This removes a reaction or reactions that are matched to the arguments. Passing in a null string to a particular argument will match all instances of that argument (like a wildcard). The null string is the default argument for all parameters.

Parameters

[in] reactionName the name of the reaciton

See also: createReaction

Definition at line 309 of file ConfigurationInfo.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ removeUserKeyword()

void ConfigurationInfo::removeUserKeyword ( const string & userKeyword = "" )

Remove a user-defined keyword. If userKeyword is not specified, all keywords are removed.

See also: userKeywords; userKeywordArguments; addUserKeyword

Definition at line 301 of file ConfigurationInfo.cc.

◆ setFitName()

void ConfigurationInfo::setFitName ( const string & fitName )

inline

Set the name of a fit.

Definition at line 405 of file ConfigurationInfo.h.

◆ userKeywordArguments()

vector< vector< string > > ConfigurationInfo::userKeywordArguments ( const string & userKeyword ) const

A list of arguments (in the form of vector<string>) associated with a given user-defined keyword.

See also: userKeywords; addUserKeyword; removeUserKeyword

Definition at line 68 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ userKeywords()

vector< string > ConfigurationInfo::userKeywords ( ) const

A list of user-defined keywords.

See also: userKeywordArguments; addUserKeyword; removeUserKeyword

Definition at line 55 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ write() [1/2]

void ConfigurationInfo::write ( const string & fileName ) const

This writes the current status of this ConfigurationInfo to a file. The output can be parsed by a ConfigFileParser object to recreate this ConfigurationInfo object.

See also: ConfigFileParser

Definition at line 424 of file ConfigurationInfo.cc.

Here is the caller graph for this function:

◆ write() [2/2]

ostream & ConfigurationInfo::write ( ostream & output ) const

Definition at line 432 of file ConfigurationInfo.cc.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

Public Member Functions

Detailed Description

Constructor & Destructor Documentation

◆ ConfigurationInfo()

◆ ~ConfigurationInfo()

Member Function Documentation

◆ addUserKeyword()

◆ amplitude()

◆ amplitudeList()

◆ coherentSum()

◆ coherentSumList()

◆ constraintMap()

◆ createAmplitude()

◆ createCoherentSum()

◆ createParameter()

◆ createReaction()

◆ display() [1/2]

◆ display() [2/2]

◆ fitName()

◆ fitOutputFileName()

◆ parameter()

◆ parameterList()

◆ reaction()

◆ reactionList()

◆ removeAmplitude()

◆ removeCoherentSum()

◆ removeParameter()

◆ removeReaction()

◆ removeUserKeyword()

◆ setFitName()

◆ userKeywordArguments()

◆ userKeywords()

◆ write() [1/2]

◆ write() [2/2]
