#include <AmpToolsInterface.h>

Inheritance diagram for AmpToolsInterface:

Collaboration diagram for AmpToolsInterface:

[legend]

Public Types
enum	FunctionalityFlag { kFull, kMCGeneration, kPlotGeneration }

Public Member Functions
	AmpToolsInterface (FunctionalityFlag flag=kFull)

	AmpToolsInterface (ConfigurationInfo *cfgInfo, FunctionalityFlag flag=kFull)

virtual	~AmpToolsInterface ()

void	resetConfigurationInfo (ConfigurationInfo *cfgInfo)

ConfigurationInfo *	configurationInfo () const

MinuitMinimizationManager *	minuitMinimizationManager () const

ParameterManager *	parameterManager () const

IntensityManager *	intensityManager (const string &reactionName) const

DataReader *	dataReader (const string &reactionName) const

DataReader *	bkgndReader (const string &reactionName) const

DataReader *	accMCReader (const string &reactionName) const

DataReader *	genMCReader (const string &reactionName) const

NormIntInterface *	normIntInterface (const string &reactionName) const

const FitResults *	fitResults () const

LikelihoodCalculator *	likelihoodCalculator (const string &reactionName) const

double	likelihood () const

double	likelihood (const string &reactionName) const

virtual void	finalizeFit ()

void	clearEvents (unsigned int iDataSet=0)

void	loadEvents (DataReader *dataReader, unsigned int iDataSet=0)

void	loadEvent (Kinematics *kin, int iEvent=0, int nEventsTotal=1, unsigned int iDataSet=0)

double	processEvents (string reactionName, unsigned int iDataSet=0)

int	numEvents (unsigned int iDataSet=0) const

double	intensity (int iEvent, unsigned int iDataSet=0) const

double	alternateIntensity (int iEvent, unsigned int iDataSet=0) const

complex< double >	decayAmplitude (int iEvent, string ampName, unsigned int iDataSet=0) const

complex< double >	scaledProductionAmplitude (string ampName, unsigned int iDataSet=0) const

Kinematics *	kinematics (int iEvent, unsigned int iDataSet=0)

void	printKinematics (string reactionName, Kinematics *kin) const

void	printAmplitudes (string reactionName, Kinematics *kin) const

void	printIntensity (string reactionName, Kinematics *kin) const

void	printEventDetails (string reactionName, Kinematics *kin) const

Static Public Member Functions
static void	registerAmplitude (const Amplitude &defaultAmplitude)

static void	registerDataReader (const DataReader &defaultDataReader)

Protected Member Functions
	AmpToolsInterface (const AmpToolsInterface &ati)

AmpToolsInterface &	operator= (AmpToolsInterface &ati)

void	clear ()

Protected Attributes
FunctionalityFlag	m_functionality

ConfigurationInfo *	m_configurationInfo

MinuitMinimizationManager *	m_minuitMinimizationManager

ParameterManager *	m_parameterManager

vector< IntensityManager * >	m_intensityManagers

map< string, DataReader * >	m_dataReaderMap

map< string, DataReader * >	m_bkgndReaderMap

map< string, DataReader * >	m_genMCReaderMap

map< string, DataReader * >	m_accMCReaderMap

map< string, NormIntInterface * >	m_normIntMap

map< string, LikelihoodCalculator * >	m_likCalcMap

AmpVecs	m_ampVecs [MAXAMPVECS]

string	m_ampVecsReactionName [MAXAMPVECS]

FitResults *	m_fitResults

Static Protected Attributes
static vector< Amplitude * >	m_userAmplitudes

static vector< DataReader * >	m_userDataReaders

static const int	MAXAMPVECS = 50

Detailed Description

A class to set up and interface with other classes within IUAmpTools.

The constructor takes a pointer to a ConfigurationInfo object; from there, all the major classes of IUAmpTools are configured and can be directly accessed via (non-const) pointers through member functions.

To reconfigure the AmpToolsInterface class with a new ConfigurationInfo object, use the resetConfigurationInfo method. This will recreate all the major classes of IUAmpTools.

Methods such as loadEvents, processEvents, decayAmplitude, and intensity are provided to perform calculations manually, which can be useful when generating Monte Carlo, for example.

For MPI implementations, use the AmpToolsInterfaceMPI class, which is derived from this class.

Definition at line 86 of file AmpToolsInterface.h.

Member Enumeration Documentation

◆ FunctionalityFlag

enum AmpToolsInterface::FunctionalityFlag

Enumerator
kFull
kMCGeneration
kPlotGeneration

Definition at line 90 of file AmpToolsInterface.h.

Constructor & Destructor Documentation

◆ AmpToolsInterface() [1/3]

AmpToolsInterface::AmpToolsInterface ( FunctionalityFlag flag = kFull )

Definition at line 55 of file AmpToolsInterface.cc.

◆ AmpToolsInterface() [2/3]

AmpToolsInterface::AmpToolsInterface	(	ConfigurationInfo *	cfgInfo,
		FunctionalityFlag	flag = `kFull`
	)

Constructor. Constructs an AmpToolsInterface

Parameters

[in] cfgInfo a pointer to a ConfigurationInfo object; IUAmpTools classes are set up and configured based on the information contained in this ConfigurationInfo object.

Definition at line 66 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ ~AmpToolsInterface()

virtual AmpToolsInterface::~AmpToolsInterface ( )

inlinevirtual

Destructor.

Definition at line 107 of file AmpToolsInterface.h.

◆ AmpToolsInterface() [3/3]

AmpToolsInterface::AmpToolsInterface ( const AmpToolsInterface & ati )

protected

Member Function Documentation

◆ accMCReader()

DataReader * AmpToolsInterface::accMCReader ( const string & reactionName ) const

Returns a pointer to a DataReader (for accepted Monte Carlo). There is one for each reaction.

Definition at line 324 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ alternateIntensity()

double AmpToolsInterface::alternateIntensity	(	int	iEvent,
		unsigned int	iDataSet = `0`
	)		const

Perform an alternate calculation of the intensity. If there are no precision problems, this should be identical to the value returned by the intensity method. This requires a prior call to processEvents.

See also: clearEvents; loadEvent; loadEvents; processEvents

Definition at line 555 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ bkgndReader()

DataReader * AmpToolsInterface::bkgndReader ( const string & reactionName ) const

Returns a pointer to a DataReader (for background). There is one for each reaction.

Definition at line 309 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ clear()

void AmpToolsInterface::clear ( )

protected

Definition at line 367 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ clearEvents()

void AmpToolsInterface::clearEvents ( unsigned int iDataSet = 0 )

For manual calculations: clear all events and calculations. Call this before loading events from a new reaction or to start new calcuations.

Parameters

[in] iDataSet used to index simultaneous manual calculations

See also: loadEvent; loadEvents; processEvents

Definition at line 405 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ configurationInfo()

ConfigurationInfo* AmpToolsInterface::configurationInfo ( ) const

inline

Return the ConfigurationInfo object stored in this class. After modifying this object, one can use the resetConfigurationInfo method to re-initialize the IUAmpTools classes.

Definition at line 135 of file AmpToolsInterface.h.

Here is the caller graph for this function:

◆ dataReader()

DataReader * AmpToolsInterface::dataReader ( const string & reactionName ) const

Returns a pointer to a DataReader (for data). There is one for each reaction.

Definition at line 302 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ decayAmplitude()

complex< double > AmpToolsInterface::decayAmplitude	(	int	iEvent,
		string	ampName,
		unsigned int	iDataSet = `0`
	)		const

Retrieve a decay amplitude calculated for the specified event. This requires a prior call to processEvents.

Parameters

[in] ampName this is the full amplitude name (as it appears in AmplitudeInfo::fullName)

See also: clearEvents; loadEvent; loadEvents; processEvents

Definition at line 516 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ finalizeFit()

void AmpToolsInterface::finalizeFit ( )

virtual

Print final fit results to a file.

Reimplemented in AmpToolsInterfaceMPI.

Definition at line 259 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ fitResults()

const FitResults* AmpToolsInterface::fitResults ( ) const

inline

Pointer to a FitResults class. Use this to access information that is stored after finalizeFit() is called.

Definition at line 197 of file AmpToolsInterface.h.

◆ genMCReader()

DataReader * AmpToolsInterface::genMCReader ( const string & reactionName ) const

Returns a pointer to a DataReader (for generated Monte Carlo). There is one for each reaction.

Definition at line 316 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ intensity()

double AmpToolsInterface::intensity	(	int	iEvent,
		unsigned int	iDataSet = `0`
	)		const

Retrieve the intensity calculated for the specified event. This requires a prior call to processEvents.

See also: clearEvents; loadEvent; loadEvents; processEvents

Definition at line 497 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ intensityManager()

IntensityManager * AmpToolsInterface::intensityManager ( const string & reactionName ) const

Pointer to an IntensityManager. There is one for each defined reaction. (Most applications will not likely need to access these.)

Definition at line 292 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ kinematics()

Kinematics * AmpToolsInterface::kinematics	(	int	iEvent,
		unsigned int	iDataSet = `0`
	)

Return the kinematics for a specified event as it was loaded using the loadEvent or loadEvents method.

See also: clearEvents; loadEvent; loadEvents; processEvents

Definition at line 483 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ likelihood() [1/2]

double AmpToolsInterface::likelihood ( ) const

Return the total -2ln(likelihood) (summed over all reactions) using the parameters stored in the ParameterManager and the amplitudes in the AmplitudeManagers. Call this before performing a fit to get the pre-fit likelihood value and call it after the fit to get the post-fit value.

Definition at line 248 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ likelihood() [2/2]

double AmpToolsInterface::likelihood ( const string & reactionName ) const

Return the -2ln(likelihood) associated with a particular reaction.

Definition at line 240 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ likelihoodCalculator()

LikelihoodCalculator * AmpToolsInterface::likelihoodCalculator ( const string & reactionName ) const

Pointer to a Likelihood calculator (one per reaction). (Most applications will not likely need to access these.) One can also access the likelihood value through the likelihood methods below.

See also: likelihood

Definition at line 340 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ loadEvent()

void AmpToolsInterface::loadEvent	(	Kinematics *	kin,
		int	iEvent = `0`,
		int	nEventsTotal = `1`,
		unsigned int	iDataSet = `0`
	)

For manual calculations: load kinematics one event at a time. Clear old events (clearEvents) before loading a new set of events. Load all events before performing calculations (processEvents).

Parameters

[in]	kin	the kinematics to be loaded
[in]	iEvent	the number of this event (between 0 and nEventsTotal-1)
[in]	nEventsTotal	the total number of events to be loaded
[in]	iDataSet	used to index simultaneous manual calculations

See also: clearEvents; processEvents

Definition at line 434 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ loadEvents()

void AmpToolsInterface::loadEvents	(	DataReader *	dataReader,
		unsigned int	iDataSet = `0`
	)

For manual calculations: load event kinematics from a DataReader. Call this after clearing old events (clearEvents) and before performing calculations (processEvents).

Parameters

[in] iDataSet used to index simultaneous manual calculations

See also: clearEvents; processEvents

Definition at line 419 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ minuitMinimizationManager()

MinuitMinimizationManager* AmpToolsInterface::minuitMinimizationManager ( ) const

inline

Pointer to the MinuitMinimizationManager. Use the methods in MinuitMinimizationManager to do fits.

Definition at line 143 of file AmpToolsInterface.h.

Here is the caller graph for this function:

◆ normIntInterface()

NormIntInterface * AmpToolsInterface::normIntInterface ( const string & reactionName ) const

Pointer to a NormIntInterface (one per reaction). Use this to access normalization integrals.

Definition at line 332 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ numEvents()

int AmpToolsInterface::numEvents ( unsigned int iDataSet = 0 ) const

The number of events that have been loaded for manual calculations.

See also: clearEvents; loadEvent; loadEvents; processEvents

Definition at line 470 of file AmpToolsInterface.cc.

Here is the caller graph for this function:

◆ operator=()

AmpToolsInterface& AmpToolsInterface::operator= ( AmpToolsInterface & ati )

protected

◆ parameterManager()

ParameterManager* AmpToolsInterface::parameterManager ( ) const

inline

Pointer to the ParameterManager. Use this to get fit results, for example.

Definition at line 150 of file AmpToolsInterface.h.

Here is the caller graph for this function:

◆ printAmplitudes()

void AmpToolsInterface::printAmplitudes	(	string	reactionName,
		Kinematics *	kin
	)		const

For debugging and diagnostics: print amplitude values to the screen in a readable format.

Definition at line 621 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ printEventDetails()

void AmpToolsInterface::printEventDetails	(	string	reactionName,
		Kinematics *	kin
	)		const

For debugging and diagnostics: print event details to the screen in a readable format.

Definition at line 723 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ printIntensity()

void AmpToolsInterface::printIntensity	(	string	reactionName,
		Kinematics *	kin
	)		const

For debugging and diagnostics: print an intensity to the screen in a readable format.

Definition at line 709 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ printKinematics()

void AmpToolsInterface::printKinematics	(	string	reactionName,
		Kinematics *	kin
	)		const

For debugging and diagnostics: print event kinematics to the screen in a readable format.

Definition at line 594 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ processEvents()

double AmpToolsInterface::processEvents	(	string	reactionName,
		unsigned int	iDataSet = `0`
	)

For manual calculations: perform all calculations on the loaded events. Load all events (loadEvent or loadEvents) before performing calculations. Returns the maximum intensity.

Parameters

[in]	reactionName	the name of the reaction that will be calculated
[in]	iDataSet	used to index simultaneous manual calculations

See also: clearEvents; loadEvent; loadEvents

Definition at line 448 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ registerAmplitude()

void AmpToolsInterface::registerAmplitude ( const Amplitude & defaultAmplitude )

static

Static function to register a user Amplitude class. For example, to register a user-defined BreitWigner amplitude, one would use: AmpToolsInterface::registerAmplitude(BreitWigner());

Definition at line 349 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ registerDataReader()

void AmpToolsInterface::registerDataReader ( const DataReader & defaultDataReader )

static

Static function to register a user DataReader class. For example, to register a user-defined CLEODataReader, one would use: AmpToolsInterface::registerDataReader(CLEODataReader());

Definition at line 358 of file AmpToolsInterface.cc.

Here is the call graph for this function:

◆ resetConfigurationInfo()

void AmpToolsInterface::resetConfigurationInfo ( ConfigurationInfo * cfgInfo )

Use this method to re-initialize all IUAmpTools classes based on information in a new or modified ConfigurationInfo object.

Definition at line 79 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ scaledProductionAmplitude()

complex< double > AmpToolsInterface::scaledProductionAmplitude	(	string	ampName,
		unsigned int	iDataSet = `0`
	)		const

Retrieve the production amplitude associated with a given amplitude. Recall that all amplitudes are defined as (production amplitude) x (decay amplitude)

The production amplitude that is returned is scaled by the scale factor that is set for that amplitude (if one has been set).

Parameters

[in] ampName this is the full amplitude name (as it appears in AmplitudeInfo::fullName)

See also: AmplitudeManager::getScale

Definition at line 543 of file AmpToolsInterface.cc.

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ m_accMCReaderMap

map<string,DataReader*> AmpToolsInterface::m_accMCReaderMap

protected

Definition at line 420 of file AmpToolsInterface.h.

◆ m_ampVecs

AmpVecs AmpToolsInterface::m_ampVecs[MAXAMPVECS]

protected

Definition at line 429 of file AmpToolsInterface.h.

◆ m_ampVecsReactionName

string AmpToolsInterface::m_ampVecsReactionName[MAXAMPVECS]

protected

Definition at line 430 of file AmpToolsInterface.h.

◆ m_bkgndReaderMap

map<string,DataReader*> AmpToolsInterface::m_bkgndReaderMap

protected

Definition at line 418 of file AmpToolsInterface.h.

◆ m_configurationInfo

ConfigurationInfo* AmpToolsInterface::m_configurationInfo

protected

Definition at line 410 of file AmpToolsInterface.h.

◆ m_dataReaderMap

map<string,DataReader*> AmpToolsInterface::m_dataReaderMap

protected

Definition at line 417 of file AmpToolsInterface.h.

◆ m_fitResults

FitResults* AmpToolsInterface::m_fitResults

protected

Definition at line 432 of file AmpToolsInterface.h.

◆ m_functionality

FunctionalityFlag AmpToolsInterface::m_functionality

protected

Definition at line 406 of file AmpToolsInterface.h.

◆ m_genMCReaderMap

map<string,DataReader*> AmpToolsInterface::m_genMCReaderMap

protected

Definition at line 419 of file AmpToolsInterface.h.

◆ m_intensityManagers

vector<IntensityManager*> AmpToolsInterface::m_intensityManagers

protected

Definition at line 414 of file AmpToolsInterface.h.

◆ m_likCalcMap

map<string,LikelihoodCalculator*> AmpToolsInterface::m_likCalcMap

protected

Definition at line 423 of file AmpToolsInterface.h.

◆ m_minuitMinimizationManager

MinuitMinimizationManager* AmpToolsInterface::m_minuitMinimizationManager

protected

Definition at line 411 of file AmpToolsInterface.h.

◆ m_normIntMap

map<string,NormIntInterface*> AmpToolsInterface::m_normIntMap

protected

Definition at line 422 of file AmpToolsInterface.h.

◆ m_parameterManager

ParameterManager* AmpToolsInterface::m_parameterManager

protected

Definition at line 412 of file AmpToolsInterface.h.

◆ m_userAmplitudes

vector< Amplitude * > AmpToolsInterface::m_userAmplitudes

staticprotected

Definition at line 425 of file AmpToolsInterface.h.

◆ m_userDataReaders

vector< DataReader * > AmpToolsInterface::m_userDataReaders

staticprotected

Definition at line 426 of file AmpToolsInterface.h.

◆ MAXAMPVECS

const int AmpToolsInterface::MAXAMPVECS = 50

staticprotected

Definition at line 428 of file AmpToolsInterface.h.

The documentation for this class was generated from the following files:

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Static Protected Attributes

Detailed Description

Member Enumeration Documentation

◆ FunctionalityFlag

Constructor & Destructor Documentation

◆ AmpToolsInterface() [1/3]

◆ AmpToolsInterface() [2/3]

◆ ~AmpToolsInterface()

◆ AmpToolsInterface() [3/3]

Member Function Documentation

◆ accMCReader()

◆ alternateIntensity()

◆ bkgndReader()

◆ clear()

◆ clearEvents()

◆ configurationInfo()

◆ dataReader()

◆ decayAmplitude()

◆ finalizeFit()

◆ fitResults()

◆ genMCReader()

◆ intensity()

◆ intensityManager()

◆ kinematics()

◆ likelihood() [1/2]

◆ likelihood() [2/2]

◆ likelihoodCalculator()

◆ loadEvent()

◆ loadEvents()

◆ minuitMinimizationManager()

◆ normIntInterface()

◆ numEvents()

◆ operator=()

◆ parameterManager()

◆ printAmplitudes()

◆ printEventDetails()

◆ printIntensity()

◆ printKinematics()

◆ processEvents()

◆ registerAmplitude()

◆ registerDataReader()

◆ resetConfigurationInfo()

◆ scaledProductionAmplitude()

Member Data Documentation

◆ m_accMCReaderMap

◆ m_ampVecs

◆ m_ampVecsReactionName

◆ m_bkgndReaderMap

◆ m_configurationInfo

◆ m_dataReaderMap

◆ m_fitResults

◆ m_functionality

◆ m_genMCReaderMap

◆ m_intensityManagers

◆ m_likCalcMap

◆ m_minuitMinimizationManager

◆ m_normIntMap

◆ m_parameterManager

◆ m_userAmplitudes

◆ m_userDataReaders

◆ MAXAMPVECS
